T3-B is an innovative stand-alone fingerprint recorder that can be used in both Time Attendance and Access Control applications and comes with TCP/IP, RS-232/485,USB,card reader, multi-functions keys and has access control connectivity for Wigand-out, Door lock connection, Alarm Clock, Exit switch. It adopts the North Korean algorithm and high image quality optical fingerprint sensor. The patented optical sensor is resistant to scratches, impact, vibration and electrostatic Shock. Industrialized design with refined fashion, integrates ZKS management software, good price with good performance. It could store 3,000 fingerprint templates and 80,000 transaction records. It is a kind of selection for your attendance and security purpose.

Technical Parameters
User capacity: 3000 (Can expand to 5000, 10000)
Transaction Storage: 80000 (Can expand to 200,000)
Period of data: Keep data for 3 years when no current
Collecting rate: Port rate (9600BPS, 19200BPS, 38400BPS)
Verification mode: 1: N, 1:1
FAR: <0. 0001%
FRR: <0. 01%
Response time: <0. 7 second
Communication: TCP/IP, 232/485,
Alarm clock: embedded alarm clock
Door access control: Connect EM lock and EM bell
The capacity of connecting net: 31 units (RS485 mode), 255 units (TCP/IP)
Distance: 1200m (RS485)
Show: Name, time, ID number
Language and voice: English, French, Spanish, Czech, Indonesian, Portuguese and Turkish etc.
Working mode: Time & attendance, standalone, can work persistently
Time & Attendance mode: Fingerprint and password
Save function: Turn off device automatically for saving
External function (access control): Connect to external E-lock, E-bell and annunciator
Size: 195*50*144mm
Power supply: DC9V, 1A (AC 100V to 240 V, 50 to 60 Hz )
Warranty of period: 24 months
Temperature and humidity: 0 - 45, 20%-80%
Optional: Proximity or Mifare card reader, USB, Backup battery
Applications: Factory/office/bank/hotel etc.
