Wine Filling Machine - GFP-12/24/32

Wine Filling Machine For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Wine Filling Machine, Made in China, High Quality Products!, China filling machine, filling machine Supplier, Manufacturer.
Wine Filling Machine

Negative Pressure Filling Machine
1. Scope of application
It is mainly used in filling of foaming liquids, such as wine, soy sauce, vinegar,pesticides,etc.
2. Principal features
Level positioning accuracy, batter than the industry standard, non-drip, tight and reliable seal.Broken bottles or none bottles not filling, not spilling fluid, clean and hygiene. Automatic adapt the error of the height of bottles, frequency conversion speed regulator, soft start, soft-breaking, non-rigid impact, stability and reliability working .
3. Principal parameter
Model
GFP-12
GFP-24
GFP-32
Production capacity
1500-2000b/h
2000-3000b/h
3000-5000b/h
Filling head
12
24
32
Bottle type
Bottle/Cans
Bottle specification
diameter60-80mm/heighet200-320mm
Cans specification
diameter50-90mm/height70-150mm
Motor power
0.75kw
1.1 kw
1.5 kw
Outer size
1000×800×2000mm
1330×1260×2200mm
1450×1700×2500mm
Weight
1000kg
1600kg
2100kg

Get Quote

Gongda Machine Co.,Ltd

Address: No.71 Gongye North Road Licheng Area, Jinan, Shandong, China, 250101
Tel: 0086-531-82378355
Shandong Gongda Machine Co., Ltd., recommended and supported by the government of Shandong Province, is a medium-sized private enterprise. It is also a technology-innovative enterprise which has been awarded numbers of honors, such as 鈥渁dvanced units of park construction鈥? "advanced enterprises of private operation鈥? "advanced collectives鈥? "youth civilization" etc., and enjoy high praise in the society. Located at No.12 of Kailua Road, of Jinan City, our company has pleasant environment and convenient transportation and covers an area of 4,000 square meters. It has a strict, efficient, united, reliable team with more than 200 technical experts and excellent management elites. Our company has cooperated with Shandong Fermentation Research Institute and Shandong Institute of Light Industry for quite long time, therefore we have cultivated many excellent scientific research and production staff. Our products include malt process devices, beer (beverage) filling lines, diatomite filters, beer keg washing machines, beer keg (bottle) filling machines, draught beer machines, preservation barrels, malt (wet , dry) mill machines, filter and press machines and so on. We have got ISO9001-2000 quality system certificate.
