Introduction
Vibrating screens operate on an inclined surface. A deck moves in a circle. It operates with a continuous feed rather than in batches, leading to much greater output. The incline allows the feed to move through the device. A circular vibrating screen?is a screening machine employed in processes involving particle separation. In particle processes screening refers to separation of larger from smaller particles in a given feed, using only the materials’ physical properties.

Features?
1. Strong vibration, high screening efficiency and low noise
2. Durable, easy to maintain, safe to use
?3. Long material screen, various sieving specification.
?4. Large capacity, less block?
5. Adjustable amplitude

?Application
The vibrating screens can be used to separate minerals into various sizes for further processing in crusher. It incorporates a?vibrator, eccentric block, mesh, spring, triangular belt and motor and is used for discharging bulky goods, sand, gravel, coal and coke from hopper to crusher. We can design and supply all ranges of vibrating screens according to the capacity and requirement.

Advantages
1) Simple structure and easy maintenance.
2) Adopting the structure of small amplitude, high frequency and large obliquity,
3) High efficiency, large handling capacity
4) Long service life, low running cost and low noise.

Working Principle
The vibrator rotates at high speeds once power is supplied. At this point, the screen rotates in a?circular motion, and then the minerals on it are sorted and filtered into the following screen according to size while the vibration and rotating motion continues to break down larger minerals, allowing them to pass through the screen. The left minerals discharge into the discharge hopper.
