Super Capacitors Module 16V120F - No.1-1
Super Capacitors Module 16V120F For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Super Capacitors Module 16V120F, Made in China, High Quality Products!, China Super Capacitors Module 16V120F,Super Capacitor Module, Supplier, Manufacturer.
Super capacitors Module 16V120FSpecification/conditionP/N：HP-2R7-J367UY? ? ? ? ? ? ?(E1A40118)Rated electro-dischange(F 25℃ ?V＝1.5V-1.25V ?I＝1A)：360Capacitance tolance：-20%～+80%Rated voltage U0 (V)：2.7Rated current（A）：50Self discharge（V after 24hours）：>2.4Temperature range：-40℃~70℃Maximum equivalent series resistance ESR(mΩ100Hz)：4Size（mm D×L）：Φ35×62Weight（g）：76Cycle life：With the rated voltage, ambient temperature circulating charge discharge experiments 500,000 times△C/C︱≤30%,ESR≤4%the initial value(25℃)Type：MK-16V-P120FDJC? ? ? ? ? ? ? ?(360F -6C2B-DJC)Voltage way：Static circuit in seriesRated capacitance（F）：120Rated voltage（V）：16Maximum equivalent series resistance ESR(mΩ100Hz)：20Size（L×W×H）mm3：200×100×100Shell：metal caseOutput mode：CableWeight（Kg）：2Temperature range：-40~65℃Storage temperature range（℃）：-40~70℃Note:the arrangement of internal monomer capacitance is 4cell*3 cross arrangement.Can be adjusted according to the actual requirements, the above parameters forthe calculation of the data for reference.Application:power system, backup power, auxiliary, wireless transmission, track dynamicsystem.
Get QuoteSHANGHAI JINPEI ELECTRONICS CO., LTD
Address: Sub lane2,Lane1028,Xiuyan Road,Kangqiao Town,201315 Shanghai, China, SHANGHAI, SHANGHAI, China, 201315
Tel: 86-21-31263693
Jinpei stablished in 1981,Website:http://www.china-jinpei.com, has more experience of the capacitors than 30 years, also was an armaments R&D and production of military聽enterprise in China.Participated in military item of the Shenzhou spacecraft/moon exploration project etc.The part products to obtain theoriginal costind of weapons-equipment production license, Found Shanghai office in 2005,mainly charge of international business.
http://www.china-jinpei.com
