Storage Battery Comprehensive Discharge Tester - SB500
Storage Battery Comprehensive Discharge Tester For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Storage Battery Comprehensive Discharge Tester, Made in China, High Quality Products!, China Battery Tester, Battery Charger Supplier, Manufacturer.
Specification：
Model 24/15 48/15 48/30 110/05 110/10 220/05 220/10
Cell voltage measurement type 2V/6V/12V
Cell voltage measurement range 2V:0~4V;6V:0~8V;12V:0~15V
Cell voltage resolution 2V/6V:0.001V;12V:0.01V
Voltage measurement range of battery string 0~30V 0~60V 0~60V 0~135V 0~270V 0~270V
String voltage resolution 0.01V 0.1V
Voltage testing accuracy 0.5%
Discharge current working range 2A~150A 2A~150A 2A~300A 2~50A 2-100A 2~50A 2~100A
Constant current discharge voltage range 21V~30V 42V~60V 42V~60V 90~140V 90~140V 180~270V 180~270V
Discharge Power Max. 4.5kw Max. 9kw Max. 18kw Max. 7kw Max. 13.5kw Max. 13.5kw Max. 27kw
Current testing accuracy 1%
Battery capacity check range 20Ah~1500 Ah 20Ah~1500 Ah 20Ah~3000 Ah 20~500Ah 20~1000Ah 20~500Ah 20~1000Ah
Current testing accuracy 1%
Capacity check testing range extension One external load added, the testing capacity range doubled
Cell data collection method wire,wireless(optional)
Monitoring current range 0~300 A
Working voltage AC220±15%
Cooling mode Refrigeration by blast
Working environment 0°C~40°C;20%~80%RH
Storage condition -20°C~70°C storage and transport
Communication mode RS232 communication
Data storage mode SD card
Display mode 4.7 inch TFT
Instrument dimensions(mm) 400*243*301 430*248*381 400*243*301
Weight(≤Kg) 14 17 14
Carry method Portable type
