sinotruk howo 30 tons dump truck, China sinotruk howo 30 tons dump truck Supplier

sinotruk howo 30 tons dump truck - ZZ3317N3667W

sinotruk howo 30 tons dump truck For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale sinotruk howo 30 tons dump truck, Made in China, High Quality Products!, China sinotruk howo, truck, dump truck, tipper Supplier, Manufacturer.

Brand: SINOTRUK HOWO Dump Truck
Truck model: ZZ3317N3667W
Traction type: 8X4
Driven type: LHD(RHD is option)
Cabin: HOWO 70 cab, flat head, tippable, flat-roof , length flat cabin, A/C
Engine model: Styre WD615.47
Engine type: 4-stroke direct injection,,6-cylinder in-line with water cooling, turbo-charging and intercooling, euro-2 emission standard
Displacement: 9.726L
Engine power: 273KW/371HP
Max torque: 1500nm/1400-1600rpm
Bore and stroke: 126X130mm
Compression ratio: 16:1
Fuel consumption: 197g/kwh
Gearbox model: Howo 18710 with 10 speed forward and 1 reverse
Front axle: HF7 elliot axle with max load 2X7000kg
Driven axle: HC16 tandem axle, pressed axle housing, double reduction with planetary wheel reduction, max load 2X16000kg
Front suspension: 9 semi-elliptic leaf springs with shock absorbers
Rear suspension: 12 semi-elliptic leaf springs with swing springs
Frame type: parallel ladder with U-profiles and riveted cross members
Steering: ZF8098
Clutch: GF430 Diaphragm type
Fuel tank: 400L
Max speed: 80km/h
Max. gradeability (%): 25
Kerb. mass: 13580kg
Total mass: 31000kg
Max load: 17700kg
Overall dimension(LXWXH): 10945X2496X3406mm
Wheelbase: 1800+3600+1350mm
Front overhang (mm): 1500
Rear overhang (mm): 800
Front track (mm): 2022
Rear track (mm): 1830
Turning circle diameter: 24m
Body dimension(LXWXH): 7600X2300X1300/1400/1500mm
Tipping type: Hydraulic Front Tipping System ------(Holland technology)
Tyre: 12.00-20/12.00R20/12.00R22.5, 13pcs

Get Quote
