SG61000-5 Professional Lighting Surge Generator for LED Luminaires Manufacture Testing
Introduction:
Automatic lightning surge generator (or Lightning surge immunity) SG61000-5 is used to assess the power cord and connect the internal switch stood in line to connect the internal switch to provide a common basis for switching the natural world and lightning caused by the high-energy transient interference performance. Performance fully meets the IEC 61000-4-5, EN61000-4-5 and GB/T17626.5 standards.
Specifications:
Product Model
SG61000-5
SG61000-5T
SG61000-5H
Wave generator
Combination Wave
Combination Wave
Combination Wave
CCITT(Option)
Output Voltage (Open)
1.2/50μs±20%
1.2/50μs±20%
1.2/50μs±20%
10/700μs±20%
Output Current (Short)
8/20μs±20%
8/20μs±20%
8/20μs±20%
5/320μs±20%
Output Impedance
2Ω
2Ω
2Ω and 500Ω
40Ω
Output Voltage Range
0~6KV±10%
0~6KV±10%
0~10KV±10%
0~6KV±10%
Output Current Range
0~3KA±10%
0~3KA±10%
0~5KA±10%
0~150KA±10%
Operation Mode
Automatic
Surge Repetition
1~9999 times
1~9999 times
1~9999 times
1~9999 times
Interval Time
20~9999s
20~9999s
20~9999s
20~9999s
Polarity
Positive, Negative or Positive/Negative automatic
Phase Shift
Asynchronous, Synchronization 0°~ 360° or Specific Angle
N/A
Coupling/Decoupling Network (CDN)
Includes a 16A single phase CDN
Includes a 20A 3phases CDN
Includes a 20A 3phases CDN
Built-in 30A 3phases CDN
Working Power
AC220V(Option 110V)±10%, 50/60Hz
Dimensions (WxDxH)
44x45x35cm
44x45x20cm and 44x45x35cm (CDN)
44x45x20cm and 44x45x35cm (CDN)
56x69x157cm (With cabinet)
Gross Weight
About 30kg
About 48kg
About 48kg
About 300kg
