Rotary die-head plastic film blowing machine - SJ-60/FM1000

Rotary die-head plastic film blowing machine For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Rotary die-head plastic film blowing machine, Made in China, High Quality Products!, China plastic film blowing machine, pe film blowing machine Supplier, Manufacturer.

Performance and Characteristics:

The cylinders and the screw stems of the extruder are made of high quality alloy steel with optimum hardness ans strong corrosion resistance after nitrogen treatment and precision finishing.The auxiliary machine has a pattorm working stable for making operation easy and is equipped with bubble stabilizing ring. Double rolling and double cutting coilling unit adopts torque motor to keep proper tension and make even and roll changing easy.
It is used for blowing various plastic film of low density polyethylene, high density polythylene and liner low density polyethylene, ect, which are widely used for packing liquid, industrial products garments and textile, etc.

Main Technical Parameter:

Type/Item SJ-55/FM800 SJ-6-/FM1000 SJ-65/FM1200 SJ-80/FM1500 SJ-100/FM2000
Dia. of screw 55mm 60mm 65mm 80mm 100mm
L/D Ratio of screw 28:1 28:1 28:1 28:1 28:1
Ratio speed of Screw 10-100r/min 10-100r/min 10-100r/min 10-100r/min 10-100r/min
Max. Output 50kg/h 65kg/h 70kg/h 86kg/h 140kg/h
Power of main motor 15kw 18.5kw 22kw 30kw 37kw
Specifiction of Die. head Φ100-150mm Φ100-180mm Φ120-220mm Φ150-300mm Φ500mm
Rotational mode of machine head contnuous ratation contnuous ratation contnuous ratation contnuous ratation contnuous ratation
Single side thickness of film 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm
Max.folding width of film 800mm 1000mm 1200mm 1500mm 2000mm
Gross power 26kw 30kw 42kw 56kw 88kw
Weight of machine 2300kg 3000kg 3800kg 4600kg 6000kg
Installing Dimension 6.0*2.0*4.0m 6.5*2.2*4.5m 6.8*2.4*4.8m 7.0*2.7*5.5m 8.0*3.2*7.6m
