当深部手术时，表面组织可能遮挡部分照明光，从而在手术区域中形成局部阴影。花瓣型号系列设置为深度照明模式，系统自动关闭无效LED光源并有选择地自动增强有效LED灯亮度修复阴影

技术参数：

技术参数明泰LED720明泰LED520

照度（勒克斯）160,000 120,000

色温（开尔文）4,300 4,300

可调色温（开尔文）（可选）3600-5600 3600-5600

显色指数（CRI）96 96

红色指数（R9）96 96

光亮度控制标准

亮度控制范围10-100％10-100％

温度上升（外科医生头）（℃）0.5 0.5

温度上升（手术野）（℃）2 2

有效聚焦深度（cm）60-150 60-150

总辐照度Ee（W / m2）530 470

Radiant Power Ee/ Ec (mW/m2lux) 3.3 3.3

Lighting Spot Size (mm) 100-260 100-260

Bulb Type LED LED

Average Bulb Life (hours) 60,000 60,000

Bulb Quantity (main bulb+ auxiliary bulb) 140LEDS+420LEDS 84LEDS+252EDS

Depth of illumination L1+L2 (cm) 130 130

Power Consumption (W) 70 50

Height adjustment (cm) 118 118

Power Input 100-240VAC, 50/60Hz 100-240VAC, 50/60Hz

Product feature:

1. Petal model series light use advanced technology, with unique performance and advantages, which can meet the various surgical lighting

2. Unique lighting depth adjustable technology

Superficial tissue may obscure part of the illumination light when deep surgery, thus forming partical shade in the surgical field. Petal model series set to deep illumination mode, the system automatically turns off the invalid LED light source and selectively automatic enhance effective led light brightness to repair shadow

3. Long life lighting source

The lifetime of LED light source is 40 times than halogen bulb, reaching 60,000H, and each led bulb can be changed separately

4. Perfect cold light effect

LED don`t engender infrared ray, temperature rising in doctor`s head is less than 0.5℃, and low temperature rising in the surgical field can prevent body fluid`s losing during operation

5. Petal model series shadowless light appearance is open type design, which meet the aerodynamic principles, and it also can reduce the light head area which will block the purify air flow, so as to minimize the light air turbulence which will affect the purification effect

6. Optional adjustable color temperature technology

Petal model series (adjustable color temperature) surgery light consists of 4 different LED bulb, by adjusting the brightness of different colors, you can adjust the color temperature between 3000-6000K to meet the doctor habits. The color temperature also can be adjusted according to the blood support quantity to distinguish different tissues

Shandong Mingtai Medical Equipment Group Co., Ltd is established in 2000 year, supporting operating room and ICU medical equipment. Since company established, continue to develop, keep making progress, let people enjoy the health future with better quality and service. Mingtai products get ISO13485, ISO9001, CE & SFDA certification. Mingtai company have many Shadowless Lamp, Surgical Table, Icu Bed and Medical Bridge Pendant patents. Mingtai brand series Operating Light, Operating Table, Medical Pendant, Hospital Bed and air disinfection equipment meet different distributor and customer`s different requirement.
