Mingtai LED720/520 standard model surgical lamp For Sale

Post Time: 2018-09-21
Mingtai LED720/520 standard model surgical lamp For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Mingtai LED720/520 standard model surgical lamp, Made in China, High Quality Products!, China Operating Light, Operating Table, Medical Pendant Supplier, Manufacturer.

明泰LED720 / 520进口配置型号  手术灯  外壳采用ABS材料,一体化设计,四个手柄环绕,流线型超薄设计,厚度不超过18CM,获得优异的层流效果

明泰LED720 / 520进口配置型号手术灯


技术参数:

技术参数明泰LED720明泰LED520

照度(勒克斯)160,000 120,000

色温(开尔文)4,300 4,300

可调色温(开尔文)(可选)3600-5600 3600-5600

显色指数(CRI)95±3 95±3

红色指数(R9)96 96

光亮度控制标准

亮度控制范围10-100%10-100%

温度上升(外科医生头)(℃)0.5 0.5

温度上升(手术野)(℃)1 1

有效聚焦深度(cm)60-150 60-150

总辐照度Ee(W / m2)450 450

辐射功率Ee / Ec(mW / m2lux)3.3 3.3

照明光斑尺寸(mm)100-260 100-260

Bulb Type LED LED

Average Bulb Life (hours) 60,000 60,000

Bulb Quantity (main bulb+ auxiliary bulb) 112LEDS+336LEDS 56LEDS+168LEDS

Depth of illumination L1+L2 (cm) 130 130

Power Consumption (W) 70 50

Height adjustment (cm) 118 118

Power Input 100-240VAC, 50/60Hz 100-240VAC, 50/60Hz





Special advantage:


1. High strength ABS material, ultra-thin light head, integrated surrounded 4 group handle design, meeting laminar flow requirements, easy to operate


2. Variety of Surgical environment lighting mode: bright, normal, endoscopic lighting mode; base axis has ambient light lighting mode (optional)


3. Satlite oval hanging main arm, meet laminar flow requirement


4. Double control system (optional), Li battery (optional), electric focus adjustment system (optional), RGBW color adjustment system (optional), independent R9 function (optional), manual focus adjustment function (standard)


5. base configuration: Germany imported Balance Arm system, light head is designed by Germany engineer, USA LED bulb, Taiwan power system




Product feature:


1. Lamp shell is ABS material, integrated design with four handles around and streamlined ultra-thin design, the thickness is not more than 18CM, obtain excellent effect of laminar flow


2. Use international advanced warm white LED as shadowless illuminant, environmental, lower energy consumption LED bulb, bulb life: ≥60000 hours


3. LED do not engender infrared ray and ultraviolet radiation, it doesn`t have the temperature rise and tissue damage caused by halogen shadowless light, can accelerate the wound healing after surgery, and has no Radiation pollution


4. LED color temperature is constant, soft and not dazzling, close to natural light


5. The main light use 112LEDS(main bulb)+336LEDS(spare bulb) independent LED illuminant (lamp cup is one main and three spare bulb structure), divided into multiple independent illuminant group, subsidiary light use 56LEDS(main bulb)+3168LEDS(spare bulb) LED illuminant (lamp cup is one main and three spare bulb structure), divided into multiple independent illuminant group; every lamp use double CPU control, every group of LED illuminant controlled by special circuit chip, any group failure will not affect the normal use of shadowless light.


6. Double switch control system, when control panel failure, emergency switch which installed on light head can be used, guarantee light normal work. Control panel in the spring arm joint, film touch switch, easy to use, Not easy to damage


7. Microcomputer digital control, illumination can be adjustable; stepless adjustment, eight segments continuous indicating, adjustment range: 10%-100%, backlight illumination: ≥30 Lux; it offers illuminance memory function


8. Adopt restrain interference design of electromagnetic wave, avoid disturb with the other equipment in operating room


9. Use satlite oval swing pipe design, can install 4 cantilever devices in complex operating room, also can be reserved per hospital`s request, convenient to upgrade and provide perfect solution for the increasing multi-media request of hospital


10. Balanced system using imported German ondal arm module, more than 5 group universal joints, every cantilever must has more than 3 joints which can be rotated in 360°, equipped with fatigue correcting unit and fix position hand handle device, easy to fix position after using for long time


11. The handle on the central of lamp can be detachable, can take high temperature (≤ 134°C) sterilization treatment, easily adjust, flexible fixed; Adopt balanced arm, handy operate, and make sure the lamp stable during operation; has C-arm joint control panel, has luminance prompt facility, provide environment lighting models


12.灯板回转半径:≥182cm,灯具可拉至垂直楼层,方便任何角度照明。统一ABS操作手柄和灯头中间操作手柄方便操作。产品执行国际IEC标准。
