High Temperature Steel Ladle Transfer Car / Battery Powered Cart Low Noise For Sale
Post Time: 2018-03-06High Temperature Steel Ladle Transfer Car / Battery Powered Cart Low Noise For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale High Temperature Steel Ladle Transfer Car / Battery Powered Cart Low Noise, Made in China, High Quality Products!, China ladle cart, transfer cart,battery cart Supplier, Manufacturer.
Application fields of Battery Powered Ladle Transfer Car
With the functions of steady traveling, stepless speed regulation, the ladle rail transport is commonly applied to ladle transfer, molten and liquid steel, aluminum ladle, furnace clinker, steel slag etc. These ladle rail transport are usually used to carry molten steel before the furnace, electric stove or converter in steel mill, foundry work, metallurgy industry, and casting factory.
Generally speaking, the outer surface temperature of the ladle is 200-300 degree , due to the high temperature, the ladle transfer bogie should be designed with heat exposure proof device, especially to the motor, reducer and electric appliance. If needed, we would prepare two motors, so when one is damaged by the ladle 's high temperature, the other one could work continually.
Main Features of Battery Powered Ladle Transfer Car
Maybe you will have a consideration before buying a car, I recommend you our products to you strongly for the following reasons:
Low noise
It's powered by electric devices, so when you are operating it, you can't feel much noise. It causes low noise level and give workers a good working environment.
Maximum safety
We always try our best to make sure the safety of the operators and the material handled. We do care the safety of everyone involved in the job.
Easy for operation
Our vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best by using our products.
Parameters of Battery Powered Ladle Transfer Car
| Model | BXC-2t | BXC-20t | BXC-50t | BXC-100t | BXC-150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size (mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Height(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 200 | 2000 | |
| Wheel Diameter (mm) | 270 | 350 | 500 | 600 | 600 | |
| Running Speed (m/min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Battery Capacity | 180 | 180 | 330 | 440 | 600 | |
| Battery Voltage | 24 | 48 | 48 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for One Charge(km) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
Contact Information
Help you to choose the most suitable cart
Thank you very much for looking through the information above. If you are interested in our products, please send us an E-mail and tell us the following information. Thank you!
- What material/cargo are you going to transfer?
- What load capacity do you want?
- What kind of ground does the transfer cart operate on? (rails or cement floor)
- What’s the specification table size ? (length,width and height)
- How long is the running distance?
- How many working hours do you have everyday?
Tags: ladle cart, transfer cart,battery cart
Get QuoteHenan Perfect Handling Equipment Co. Ltd
Address: 7th, Jiayi Oriental Pearl Building, Northwest of Xinzhong Road and Jinsui Road,Xinxiang, Henan, 453000
Tel: +8603733020116
Henan Perfect Handling Equipment Co., Ltd is a professional & international manufacturing factory specialized in researching, developing, producing and selling material handling equipment.
We have got CE, SGS, ISO, CO certificates about our products, and our products have been exported to more than 30 countries and regions.
based on modern plant and advanced production equipment, we can produce all kinds of handling equipment from 1-1300 tons, our main products including BDG conductor rail equipment, BJT cable drum type, BHX safety sliding line type, BXC battery type, BTL towed cable type, BP non-power type, BQY train towed type, BWP trackless type and special type, such as turning cart, trackless cart, ladle car, hydraulic lifting car, ferry car, painting room car, blasting booth car, etc.
