Pharmaceutical Hard Gelatin Capsule Filling Machines Size 00# 0# 1# - NJP-400 / 600 / 800
Pharmaceutical Hard Gelatin Capsule Filling Machines Size 00# 0# 1# For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Pharmaceutical Hard Gelatin Capsule Filling Machines Size 00# 0# 1#, Made in China, High Quality Products!, China cheap prodocuts, china suppliers Supplier, Manufacturer.
?
?
NJP-400 / 600 / 800 Automatic Capsule Filling Machine size 00# 0# 1# 2#?3# 4# 5#
?
?
Features
1. Electrical Appliance control system approved to CE, and international standard.?
2. Fully closed rotating table and dosage stations for integration of the whole capsule filling plants, which conforms to GMP norms.?
3. Large cam mechanism keeps the rotating table of mould together with the whole equipment running in balance, and completely guarantees the machine operating with highest precision and accuracy.?
4. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.?
5. Quick and accurate part changing system, easy to remove rotary table and ring carrier assembly.?
6. Capsule vacuum positioned mechanism to make the capsule qualified over 99%.?
7. Touching-Screen, PLC program control panel with LCD.?
?
?
Specification
?
- - - -
Machine model
? | NJP-800
? | NJP-600
? | NJP-400
? |
Max capacity
? | 48000 capsules/hour
? | 36000 capsules/hour
? | 24000 capsules/hour
? |
Suit for capsule size
? | 00#-5#and safety capsule
? |
No. of mould bores
? | 6
? | 5
? | 3
? |
Machine dimensions
? | 1080x1240x1950 mm
? | 1080x1240x1950 mm
? | 1080x1240x1950 mm
? |
Net weight
? | 800 Kg
? | 800Kg
? | 800Kg
? |
Power
? | 380/220V 50/60Hz 5kw
? | 380/220V 50/60Hz 5kw
? | 380/220V 50/60Hz 5kw
? |
Vacuum
? | 20m 3 /h-0.02-0.05MPa
? | 20m 3 /h-0.02-0.05MPa
? | 20m 3 /h-0.02-0.05MPa
? |
Dust Exhaust
? | 220m 3 /h 2x10P 5 a ??
? | 220m 3 /h 2x10P 5 a
? | 220m 3 /h 2x10P 5 a ??
? |
Noise
? | <75dB
? | <75dB
? | <75dB
? |
- - - -
?
?
NJP-400 / 600/ 800 adopt PLC control system, human-machine interface, when running malfunction or lack of stuff, automatic alarm, malfunction display, automatic dismiss alarm. And with functions of password setup, touching screen display, automatic parameter setup, data printing, reset, etc.
The jump-start axed, cam and other main damageable parts all adopt imported materials. And the machine is suitable for Powder, Granular and Pellet filling, one hour for 12,000/24,000capsules, special for Capsule size from 00# to 5#.
?
?
Competitive Advantage:
?
1. The patent technology of dual gas supply increases the feeding rate of capsules and prevents the capsules from being broken.
2. The extremely low design of the turntable reduces the inertia of the turntable and the abrasion of the spare parts, prolongs the shelf life of the cam dividing box and keeps the stability for the whole machine.
3. The filling system adopts the inside cam instead of the traditional working rod to increase the filling powder and reduce the vibration and noise.
4. The machine has gained more than 20 technical patents in China.
5.This machine has been ownly developed through absorbing advantages on the base of the same products with higher price than the old model type machinery.
?
Zhejiang Wisely Machinery Co., Ltd.
Address: 51 Kafayi Road, Economic Development Zone, Wenzhou, Zhejiang, China, 325000
Tel: 86-577-65155503
Zhejiang WISELY Machinery Co., Ltd. (formerly known as Rui'an HUADA Pharmaceutical Machinery Factory), established in 1992, is a member of China Association for Pharmaceutical Equipment and a vice-chairman unit of Wenzhou Council for Promotion of Private Enterprises. It is a national hi-tech enterprise integrating research, development, design, production and technical services and one of the five national key enterprises in manufacturing capsule filling machines. It is located in the economy development zone of Rui'an, Zhejiang province, with a plant area of more than 13000 square meters and a construction area of 14000 square meters.
WISELY specializes in producing pharmaceutical equipment, and the main products are the fully-automatic NJP-series capsule filling machines. WISELY as well as its products has passed the ISO9001 and CE certification, and has gained more than 50 honors from national, provincial and municipal government. Its products sell well both at home and abroad, including up to 30 provinces in China and more than 20 countries and regions around the world. The fully-automatic WISELY branded capsule filling machine is the most advanced self-developed products, and gains completely independent intellectual property rights. It is listed as "National Key New Product" by the State Ministry of Science and Technology and is titled as "Wenzhou Brand-name Product". There are more than 50 Chinese patented technologies used in the machine, which solves a lot of technical problems on similar products both at home and abroad. The online capsule weighing and sorting system is listed as "Important Science and Technology Planning Project of Zhejiang Province" by the Science and Technology Agency, and the new generation of capsule filling machines has gained support from the National Science and Technology Innovation Fund in 2013. Besides, we also have products such as packing machine, Tablet pressing machine and so on.
