Introduction of Inclined-jet turbine

Inclined-jet turbine: The pressure energy of water flow is changed to velocity energy by the nozzle, since leaving the nozzle, the water flow is not in a closed system, but forms the free jet in the spiral casing filled with atmosphere, and at the same time there are 3-4 buckets receiving the free jet from the same nozzle with unequal-sized discharge. There was a fixed angle (usually take 22.5 degree) between the jet center of nozzle exit and the inlet water plane of runner.


Characteristics and application scope of Inclined-jet turbine:

Application scope of heads: 15m~300m
Applicable discharges: Q=0.089~8.30m3/s
Runner diameters: 0.05m ~ 5m
Installable capacity: 500KW ~ 6000KW
Specific ratio speed: 18 ~ 45

We also providing different kinds of water turbine generator:

1.Francis Turbine
2.Pelton Turbine
3.Inclined-jet water turbine
4.Cross flow water turbine
5.Tubular water turbine

Company Introduction
Found in 1958, our factory in hydropower products has continuously been one of the national strategic turbine manufacturers in China since year 1995. It has now 246,000 square meters ground area and 68,000 square meters office building area. With over 500 workers and over 200 technicians and engineers, ADDNEW& acute;s invested factory is certificated by ISO9000-2000 and CE.
