JZB240 pile driver machine Walking Piling Frame for pile foundation worksJZB240 walking piling frame,Website:http://www.zzpiling.com, jointly developed by beijing construction machinery comprehensive research institute and zhejiang zhenzhong construction machinery co.,ltd, is a new generation large-scale walking piling frame. The product features innovative design, rational structure, advanced technology, superior performance and stable and reliable application. It can be ?applied to a variety of foundation construction, especially to meet the soil mixing wall method. It is the ideal and efficient equipment for the foundation construction of highways, bridges, ports, docks, subway stations and high-rise building.It has the following features1.stable and efficient piling frame system2.various power head, jackrod and drilling tool3.comfortable cab, convenient and simple operating system for single person4.convenient installation and transportation5.provide inductive load angle monitor and deep mixing pile monitor, which are conductive to conduct operation and construction managementJZB240Height of mast39.52mMast supporting mode3-point supporting typeMast inclinationForward12°Backward 5°Travel modeWalking typeLateral Travel speed2.9/4.8m/minLengthways Travel speed1.5/2.9m/minOverall dimensions in operation15.35m×9.6m×42.25mMax. Extraction Force710 kNMain Winch pull(1st layer)91.5 kNRope diameter21.5mmDrum capacity550mWinding speed0~26 m/minAuxiliary winch pull(1st layer)72 kNRope diameter20mmDrum capacity250mWinding speed0~32 m/minTotal Weight138TPackaging & ShippingDelivery it without package and some parts should be packaged in wooden case.And it’s better to delivery it in bulk ship.JZB240 pile driver machine Walking Piling Frame works with power headJZB240 pile driver machine Walking Piling Frame works with dual power headJZB240 pile driver machine Walking Piling Frame works with power head in Wenzhou
