High Pressure Gas Compressors

with Large Flow

SHINEEAST Gas Compressors are widely used in kinds of industries and testing equipments, with output pressure up to 400 bar.

The output pressure of the gas compressors is 10-400bar, with output flow max. 1200m³/hr; the power is from 2.2KW to 75KW, including single stage compression and double stage compression.

The gas compressor can be used for nitrogen gas, helium gas, methane, CO2, argon gas, dry air etc.

Technical parameters:
GL Series gas compressor:

Specification	Outlet pressure (MPa)	Inlet pressure (MPa)	Flow(m³/hr)	Motor power (KW)
ST10-2.2-GL	10	1.4-10	8-60	2.2
ST10-4-GL	10	1.4-10	14-100	4
ST10-7.5-GL	10	1.4-10	25-180	7.5
ST10-11-GL	10	1.4-10	40-300	11
ST10-15-GL	10	1.4-10	55-380	15
ST10-30-GL	10	1.4-10	110-780	30
ST10-45-GL	10	1.4-10	170-1200	45

ST20-2.2-GL	20	2.8-20	7-55	2.2
ST20-4-GL	20	2.8-20	12-90	4
ST20-7.5-GL	20	2.8-20	24-180	7.5
ST20-11-GL	20	2.8-20	40-280	11
ST20-15-GL	20	2.8-20	50-360	15
ST20-30-GL	20	2.8-20	110-750	30
ST20-45-GL	20	2.8-20	160-1100	45

ST40-2.2-GL	40	5.5-40	6-45	2.2
ST40-4-GL	40	5.5-40	10-80	4
ST40-7.5-GL	40	5.5-40	20-150	7.5
ST40-11-GL	40	5.5-40	36-240	11
ST40-15-GL	40	5.5-40	45-320	15
ST40-30-GL	40	5.5-40	100-650	30
ST40-45-GL	40	5.5-40	150-1000	45
