Heavy Duty Plate Beveling Machine
CJ-100L Edge Beveling Machine
CJ-100L steel plate edge milling machine is primarily designed for bevel cutting and clad removal/strip on steel plates made of materials such as mild steel, stainless steel, aluminum steel, alloy titanium, Hardox, duplex, and more. The CJ-100L is a heavy-duty plate beveling machine equipped with two milling heads, capable of handling plate thicknesses ranging from 6 to 100mm. It offers adjustable bevel angles ranging from 0 to 90 degrees. The CJ-100L can achieve a 30mm bevel per cut, making it highly efficient. With just 3-4 cuts, it can achieve a bevel width of up to 100mm, significantly improving efficiency and resulting in time and cost savings
| Models | CJ-60S | CJ-60L | CJ-80A | CJ-80R | CJ-100L | CJ-100K | GCM-R3TD | GCM-R3AR |
| Power Suppy | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ |
| Total Power | 4520W | 4520W | 4920W | 4920W | 6520W | 6480W | 1900W& 0.5-0.8 Mpa | 1900+400W |
| Spindle Speed | 1050r/min | 1050r/min | 500~1050r/min | 500-1050mm/min | 500-1050mm/min | 500~1050r/min | 2800r/min | 2800r/min |
| Feed Speed | 0~1500mm/min | 0~1500mm/min | 0~1500mm/min | 0~1500mm/min | 0~1500mm/min | 0~1500mm/min | 0~4000mm/min | 0~4000mm/min |
| Clamp Thickness | 6~60mm | 6~60mm | 6~80mm | 6~80mm | 6~100mm | 6~100mm | 8~60mm | 8~60mm |
| Clamp Width | >80mm | >80mm | >80mm | >80mm | >100mm | ≥100mm | ≥100mm | ≥100mm |
| Clamp Length | >300mm | >300mm | >300mm | >300mm | >300mm | ≥400mm | ≥300mm | ≥300mm |
| Bevel Angel | 0~60 degree | 0~90 degree | 0~60 degree | 0~±60 degree | 0~90 degree | Top 0~90 ° and Down 0~-45° | / | / |
| Singel Bevel width | 0-20mm | 0-20mm | 0-20mm | 0-20mm | 15-30mm | 0-20mm | 3mm | 3mm |
| Bevel Width | 0-45mm | 0-60mm | 0-70mm | 0-70mm | 0-100mm | Top 0~60mm and Down 0~45mm | C2/C3/R2/R3 | R2/R3 |
| Cutter Diameter | Dia 63mm | Dia 63mm | Dia 80mm | Dia 80mm | Dia 100mm | 2 * Dia 63mm | 2 * Dia 60mm | 2 * Dia 60mm |
| Inserts QTY | 6 pcs | 6 pcs | 6 pcs | 6 pcs | 7 pcs/9pcs | 2 *6 pcs | 2 *3 pcs | 2 *3 pcs |
| Worktable Height | 700-760mm | 700-760mm | 700-760mm | 700-760mm | 810-870mm | 810-870m'm | 800-860mm | 730-790mm |
| Suggest Table Height | 730mm | 730mm | 730mm | 730mm | 830mm | 830mm | 830mm | 760mm |
| Worktable Size | 800*800mm | 800*800mm | 800*800mm | 1200*800mm | 1200*1200mm | 800*800mm | 1200*900mm | 1000*1000mm |
| Clamping Way | Auto Clamping | Auto Clamping | Auto Clamping | Auto Clamping | Auto Clamping | Auto Clamping | Auto Clamping | Auto Clamping |
| Wheel Size | 4 Inch STD | 4 Inch STD | 4 Inch STD | 4 Inch Heavy duty | 4 Inch Heavy duty | 4 Inch Heavy duty | / | 4 Inch STD |
| Machine Height Adjust | Hydraulic | Hydraulic | Hydraulic | Handwheel | Handwheel | Handwheel | Handwheel | Handwheel |
| Machine N.Weight | 200 kgs | 225 kgs | 245 kgs | 310 kgs | 420 kgs | 395 kgs | 380kg | 300kg |
| Machine G Weight | 255 kgs | 260 kgs | 280 kgs | 380 kgs | 480 kgs | 460 kgs | 430kg | 380kg |
| Wooden Case Size | 800*690*1140mm | 950*700*1230mm | 800*690*1140mm | 1100*630*1340mm | 950*1180*1430mm | 950*1180*1430mm | 1400*1200*1230mm | 950*700*1230mm |
