GTR Intermediate Frequency Heating Furnace - GTR
GTR Intermediate Frequency Heating Furnace For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale GTR Intermediate Frequency Heating Furnace, Made in China, High Quality Products!, China induction heating furnace, medium frequency heating furnce Supplier, Manufacturer.
GTR Intermediate Frequency Heating Furnace Technology Specifications:
Model Power Input Power Output
Inlet Wire Voltage(V)
3 phases or 6 phases
50HZ Inlet Wire Currency (A) DC Voltage(V) DC Currency (A) Frequency (KHZ) Voltage ±10%(V) Power (KW)
GTR-60 380 100 500 120 1-8 750 60
GTR-100 380 160 500 200 1-8 750 100
GTR-120 380 200 500 240 1-8 750 120
GTR-160 380 260 500 320 1-8 750 160
GTR-200 380 330 500 400 1-8 750 200
GTR-250 380 410 500 500 1-8 750 250
GTR-300 380 490 500 600 1-8 750 300
GTR-400 380 650 500 800 1-8 750 400
GTR-500 380 820 500 1000 0.4-8 750 500
GTR-750 380 1200 500 1500 0.2-6 750 750
GTR-750 660 680 890 850 0.2-6 1300 750
GTR-1000 380 1650 500 2000 0.2-6 750 1000
GTR-1000 660 920 890 1150 0.2-6 1300 1000
GTR-1500 380 2500 500 3000 0.2-1 750 1500
GTR-1500 660 1400 890 1700 0.2-1 1300 1500
GTR-2000 580 2100 780 2600 0.2-1 1170 2000
GTR-2000 660 1850 880 2300 0.2-1 1300 2000
GTR-2000 1250 1000 1650 1200 0.2-1 1300 2000
GTR-2500 580 2600 780 3200 0.2-0.5 1170 2500
GTR-2500 660 2300 880 2850 0.2-0.5 1300 2500
GTR-2500 1250 1300 1650 1500 0.2-0.5 1300 2500
GTR-3000 580 3100 780 3850 0.2-0.5 1170 3000
GTR-3000 1250 2800 1650 240 0.2-0.5 2
Production Description:
1) Intermediate Frequency Heating Furnace
2) Easy Operation and maintenance
3) Good heat uniformity, small temperature difference on core surface, high control accuracy
4) Energy saving, lower cost than coal furnace
Huaxin Electric Furnace Manufacturing Co.,Ltd
Address: No.1 Industry Street, Economic Technical Develop Zone, weifang, shangdong, China, 262737
Tel: 8605368535920
Weifang Jinhuaxin Electric Furnace Manufacturing Co., Ltd., Established on 1998, has capital assets 600 million RMB, located in Weifang City- Wold Kite Capital, covers area of 20000 m2, is high technology enterprise, professionally research, develop and manufacture Induction Heating Equipment. Passed ISO9001:2008 on year 2009.
