Glass Edging/Seaming Machine

LJGSL-9243 glass straight line edging machine is designed for grinding straight edges or 45 angles and flat glass of different sizes and thickness. Crude grinding, refine grinding, polishing, and angle making can be completed in one procession.

LJGSL-9243 glass straight line edging machine is designed for grinding straight edges or 45 angles and flat glass of different sizes and thickness. Crude grinding, refine grinding, polishing, and angle making can be completed in one procession.

1. Grinding speed：0.5~5m/min

2. thickness：3~19mm

3. Minimum size of glass：100 x 100mm

4. Maximum size of glass： 2440 x3660mm

5. total power：19kw

6. weight：2700kg

7. occupation area：6500 x 1500 x 2200mm (L x W x H)
