Plate and frame filter is a set of coarse filter, fine filter, ultrafiltration and a product, the main purpose is based on user requirements for the production of products, and use different filter devices to filter the liquid to clarify the filter. The product structure is novel, compact, handsome in appearance, easy to operate mainly for the processing of electrolytic processing products. Working principle of plate and frame filter pressPlate and frame filter press is composed of a series of filter plates arranged alternately. The surface of the filter plate has a groove, and its protruding part is used to support the filter cloth. There are through holes in the corners of the filter plate, after assembly to form a complete channel. Filter plate on both sides of each handle in the beam on the beam, pressed by the clamping device filter plate. Filter box between the filter cloth from the role of filtration by the feed pump will filter into the filter chamber, a clean filter through the filter cloth and along the filter plate trench to the edge of the filter plate channel, concentrated discharge, formed on the filter cloth Filter residue, until the filter chamber or reach the predetermined pressure, filtration is completed, access to compressed air to remove the water retained in the channel, then open the filter to remove the filter residue, cleaning filter cloth, re-compacting plate, start the next work cycle.Plate and frame filter press mainly by the thrust plate (fixed filter plate), compression plate (active filter plate), filter plate, beam (garden type corrosion), clamping device, sump and other components (see photos). Filter area can be increase with the number of frame used.
