Facial recognition time attendance and access control terminal HF-FR202
Introduction:
FR202 multi-biometric identification time attendance and access control terminal adopts HF&CCTV’s latest ZEM800 platform with HF Face 7.0 algorithm and large capacity memory. FR series integrated 630MHz high speed ZHF Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of FR are designed to be performed on the 4.3 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional WiFi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure.

Features:
Identification methods include Face, Fingerprint/RFID and/or Password
Elegant ergonomic design
4.3’’ TFT touch screen is user-friendly and very intuitive
6 user-defined function keys
Contact relays for door access control (wires to door strike or 3rd party panel)
Web server management software via IE browser.
Optional extendable scheduled-bell
Infra-red optical system enables user-identification in poorly lit environments
Optional built-in battery backup provides approx 4 hours continuous operation.
Optional built-in wireless Wi-Fi or GPRS for wireless communication.
Built-in contacts for 3rd party electric lock, door sensor, alarm, exit button, or bell.
Wiegand Output for connections to 3rd party access control panels.

Connection Diagram:

Specifications:
CPU HF Multi-Bio CPU 800 MHz
Memory 256M Flash, 64M SDRAM
Hardware Platform ZEM800 Multi-Medium Development Platform
Fingerprint Sensor HF Optical Fingerprint Sensor without film
Camera High Resolution Infrared Camera
Display 4.3’’ TFT touch screen
Face capacity 400 (1:N)
Fingerprint capacity 2000
Logs capacity 100,000
Algorithm Version HF Face 7.0 & HF Finger 10.0
2000mAh backup battery Optional
Communication TCP/IP,RS232/485
USB-HOST
