Extrusion Line For XPS Foam Profile
75-200
XPS Foam board line is mainly composed of six parts of mixing system, extruder, foam agent injection system, traction system, conveying & cutting system, recycling& pelletizer system. Our product has the advantages of excellent configuration, reasonable design, high output, low energy consumption and extremely high stability.
The main configuration:
Raw material mixture and auto conveying equipment.
75 parallel twin-screw extruder.
High pressure foam agent injection system.
Type 150 extruder.
Extrusion head.
Foam table.
Primary tractor.
Transfer& Cooling rack.
Secondary tractor and width cutting equipment.
Length cutting equipment.
Recycling & Pelletizer system.
Model | Primary Extruder Screw | Secondary Extruder Screw | Product Width (MM) | Product Thic kness(MM) | Output(KG/H) | Size(M"M"M) | Weight(T) |
| SXPS -75/150 | 75 | 150 | 600~1200 | 17~100 | 200~400 | 60*10*4 | 26 |
| SXPS -75/200 | 75 | 200 | 600~1200 | 20~120 | 300~500 | 70*10*4 | 31 |
| SXPS -95/250 | 95 | 250 | 600~1500 | 20~150 | 400~700 | 80*12*4 | 37 |
