DWX Suspension single hydraulic prop pipe for mine supporting in China

Technical parameters:

Project / model


DW45-250/110XL(G)

DW42-250/110XL(G)

DW40-250/110XL(G)

DW38-250/110XL(G)


Working resistance

F1 KN

250


Work of the hydraulicP1 MPa

28.34


The initial supporting force

F2 KN

132.4~176.7


The pump station pressureP2 MPa

15~20


The maximum height

Hmax mm

4500

4200

4000

3800


The minimum height

Hmin mm

2533

2373

2263

2153


Working stroke

mm

1967

1827

1737

1647


Weight

w kg

102.4

96.78

92.94

89.1
