Decoration Coating Machine Ebeam Evaporation Machine Deposition System
This equipment is designed for coating precision optical thin film,each system unit and overall structure well meet the optical thin film production process requirements,which suitable for coating anti-reflection film, bandpass film ,IR-Cut filter etc.It equipped with high-precision film thickness control system,excellent performance electron gun,high degree automation coating control system, etc. It& acute;s the ideal equipment for coating high precision optical thin film.
Model:ZZS-800 Optical thin film coater
Vacuum Chamber:SUS304,Φ800mm×H900mm
Substrate Dome Size:Φ750mm
Substrate Dome Rotation Speed:3rpm to 30rpm(Variable)
Optical Film Thickness Control System:SQC310+6point rotary sensor,full automatic coating control system
Evaporation Source:5kw EB source: 1 units, resistance evaporation
Vacuum System:Rotary Pump + Roots Pump +Diffusion Pumps
Ultimate Vacuum:4.0×10-3Pa
Recover vacuum:from atmosphere to 4 x 10-3 Pa≦12min.
Substrate Heater:350℃ (max.)
Power Requirements:three-phase ,220V/380V±5%,50HZ
Cooling Water Flow Rate:100 /min or greater
Compressed Air Pressure:0.6～0.8MPa
Optical Thin Film Application:
1.For clean energy:
Transparent conductive film, IR cut coating, decoration coating etc.( LED )
2.For display:
AR Coating, Dichroic Mirror, PBS, Cold Mirror etc.
AR/AS(AR/Anti Electromagnetic wave coating) etc.
ITO Transparent Conductive Film etc.(Optical parts and lenses in liqid crystal)
3.For Optical Communication:
NBPF, BBPF, Edge filter, AR Coating, GFF etc.( DWDM Filter )
4.Semiconductors:
AR Coating, BPF, Edge filter, HR Coating etc.(lenses and optical parts for semiconductor industry facilities laser, optical switch)
5.Optical Storage Media:
AR Coating, BS Coating etc.( optical parts and components for optical disks such as DVD,CDRW,CDR,CD)
6.For Bio-Industry :
BPF,Edge filter,AR Coating,Mirror, HR Coating,Cold Mirror etc.( Optical parts and lenses in liqid
