Combined Machine for Cleaning, Drying and Pouring Water
The combined machine is equipped with clamping device and gear motor, which make the machine have the function of turning over gas cylinder 180 degrees, this can realize gas cylinder pouring water; the machine is also equipped with one high pressure water pump and one steam vapor machine, the high pressure water pump is in charge of cleaning the internal of the cylinder, and the steam vapor machine is used for drying the internal of the cylinder.
The process sequence of the machine is pouring water—cleaning the inside of cylinder---drying the inside of cylinder.
The machine is applicable to the cylinders with diameter between 200mm and 406mm, with height 700-1300mm; and it can deal with one gas cylinder at one time.
Model: CM-01-01
Applicable cylinder size: Outer diameter:200-406cm, height:700x1300mm
Overturn speed: 3.8 r/min
Gear motor: 2.2KW/380V
Dryer part (vapor generator): 9KW/380V
Water pump for cleaning the cylinder: 0.75KW/380V
overturn angle: 180°
Air pressure: 3-8 bar
No. of station: One station
Main parts of the machine: Overturn stand, control panel, gearbox, water pump, vapor generator etc.
