CNC Color Steel Sheet 914 Large Span Arch Forming MachineThe products looks very beautiful and have a high strength,its widely used as the roof of the factory,garden,hotel,exhibition center,etc!Main Technical Specification HT-240(610)1.Size:9500mmx2270mmx2400mm2.Total Weight:About 12000kg3.Controlling System:PLC4.Forming Power:7.5kw5.Bending Power:4.0kw+1.5kw+1.5kw6.Cutting Power:3.0kw7.Material of rollers:45#steel,quenched HRC 58-628.Material of roller shafts:45#steel9.Material of cutting blade:Cr12 steel10.PLC Type:Siemens11.Step of rollers:13 steps12.Feeding Width:914mm13.Effective Width:610mm14.Thickness of the coil:0.6-1.6mm15.The depth of the groove:203mm16.Working speed:Straight sheet:15m/min17.Arch sheet:13m/min18.Sewing:10m/min19.Max span:38mMain Technical Specification HT-120(305)1.Size:8800mmx2050mmx2000mm2.Total Weight:About 9000kg3.Controlling system:PLC4.Main forming unit driving motor power:5.5kw5.Curving motor power:3KW+1.5KW6.Electric cutting power:3kw7.Material of roller:45#steel,quenched HRC58-628.Material of roller shafts:45#steel,adjusted9.Material of cutting blade:Cr1210.Step of rollers:13 steps11.Feeding Width:600mm12.Effective Width:305mm13.The depth of the groove:109mm14.Thickness of the coil:0.6-1.6mm15.Working speed:Straight sheet:15m/min16.Arch sheet:13m/min17.Sewing:10m/min18.Max span:24mFEATURES:HIGH SPEED OF CONSTRUCTION(With our LSMBM Mobile Factory,a 1000-square meter structure can be built in 24 hours).LOW COSTMOBILITY AND ACCESS TO REMOTE AREASNO STRUCTURAL COLUMNS,BEAMS OR TRUSSES REQUIREDSAVINGS IN MANPOWER(Our crew of approximately 10 to 15 trained men can erect a 1000 square meter building in a single day).Machine Components:a)Decoilerb)Roll-forming devicec)Hydraulic cutterd)PLC control systeme)Curving devicef)Necessary accessoriesWorking flow:Decoiler---Feeding---Roll forming---Cutting---Curving---Output table
