CNC 3020 200W Engraving Machine for woodworking - CNC 3020
CNC 3020 200W Engraving Machine for woodworking For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale CNC 3020 200W Engraving Machine for woodworking, Made in China, High Quality Products!, China Stainless Steel Carving Machine, Advertising Board engraving machine Supplier, Manufacturer.
Specifications
Model
CNC3020
Dimension
62x41x31cm
Work area
450x240mm
X,Y,Z axis woking travel
300x200x80mm
The Max thickness of Carved objects
65mm
Rack material
6061+6063Aluminum alloy
Transmission unit
X ,Y,Z axis is 1204 T Screw
Sliding unit
X:Φ13,Y:Φ16,Z:Φ12
Consumption
DC110V,240W
Spindle Power
200W/AC220, SCM stepless speed regulation
Speed (r/pm)
0-8000
Clamping diameter
3.175mm
Cooling way
air cooled
feeding speed max(mm/min)
4000
Carving speed(mm/min)
0~1000
Carving accuracy
0.03mm
Repositioning Accuracy
(mm)
0.03mm
Input voltage
220V or 110V
Instruction format
G code (tap, nc, ncc, text)
Compatible software
Mach3/TYPE3/ArtCAM/CAD/CAM etc
Features:
1. Steel Gantry, Cast Iron uprights . No deformation.stable running .High rigidity.
2. Y adopt durable driving by synchronizing wheel consist of belt and gear shaft . Big power sub-division motors keep stable moving, improve your working efficacy.
4. It will start the work automatically at the point from which the power cut off. More intelligent.
5. Using quality sensor switch, improve the machine working safty .
6. Machine comes with Dust Collection system, Make sure clean circumstance.
Application:
1. Wood industry:Stereo Wave Plate Processing, cabinet doors, solid wood doors, Craft wood door, paint free door, folding screen, craft window, shoe-cleaning machine, game cabinet, mahjong table, computer table, and panel-type furniture’s assistance processing.
2.Advertisement industry: Advertisement label and logo, Acrylic cutting and blister molding, Multi Ad. Material and decoration products processing.
3. Mold industry:Engrave on material like brass, Al, and Iron to make metal mold. And it can engrave on artificial Marble, gravel, plastic board, PVC pipes, wood, and alike Non-metal mold.
