Ceiling Suspension Grids, Ceiling T Bar/Standard T Bar, Alloy Head Ceiling Tee Grids, China Ceiling Suspension Grids, Ceiling T Bar/Standard T Bar, Alloy Head Ceiling Tee Grids Supplier

Ceiling Suspension Grids, Ceiling T Bar/Standard T Bar, Alloy Head Ceiling Tee Grids - baier801

Ceiling Suspension Grids, Ceiling T Bar/Standard T Bar, Alloy Head Ceiling Tee Grids For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Ceiling Suspension Grids, Ceiling T Bar/Standard T Bar, Alloy Head Ceiling Tee Grids, Made in China, High Quality Products!, China Ceiling Suspension Grids, Ceiling T Bar Supplier, Manufacturer.

Item Specification PCS/M2 Notes
Main Tee 38*24*3600mm 0.225 a. The thickness can be 0.23mm to 0.4mm according to customers& acute; requirement.

b. The sizes can?be made to customers& acute; order.
32*24*3600mm
Cross Tee 38*24*1200mm 1.35
32*24*1200mm
26*24*1200mm
Sub Cross Tee 38*24*600mm 1.35
32*24*600mm
26*24*600mm
Wall Angle 24*24*3000mm 2
22*22*3000mm
20*20*3000mm
??
What& acute;s the materials of our ceiling T grid?

?1,Zinc.60-270g Hot dipped Galvanized steel coil.

2,Prepainted galvanized steel coil.

3,Above materials also canbe customzied.

What& acute;s the specification of our Ceiling T grid?
?
Name Type Dimension(mm) Width(mm) Length(mm) Thickness(mm)
?
?
Main?tee
? 38T?Flat 38×24 24 3600/3660 0.2-0.35
32T?Flat 32x24 24 3600/3660 0.2-0.35
?
Cross?tee 26T?Flat 26×24 24 1200/1220 0.2-0.35
24T?Flat 24×24 24 1200/1220 0.2-0.35
?
Cross?tee 26T?Flat 26×24 24 600/610 0.2-0.35
24T?Flat 24×24 24 600/610? 0.2-0.35
?
Wall?angle L-shaped 22×20 ? 3000 0.2-0.35
L-shaped 24x24/22x22 ? 3000 0.2-0.5
Name Type Dimension(mm) Width(mm) Length(mm) Thickness(mm)
?
?
Main?tee
? 28T?groove 28×24 24 3600/3660 0.2-0.35
32T?groove 32×15 15 3600/3660 0.2-0.35
?
Cross?tee 32T?groove 32×15 15 600/610 0.2-0.35
28T?groove 28×24 24 600/610 0.2-0.35
?
Wall?angle L-shaped 22×20 ? 3000 0.2-0.5
L-shaped 24×24 ? 3000 0.2-0.5
Note:Other size and thickness canbe customized.

Because professional,so rest assured!
?
24hours on line or email /phone service.
If you have any inquiry about?gypsum board and pvc gypsum ceiling tiles business ?, pls feel free to contact us. Thank you?!

Get Quote

pingyi baier building material co,ltd

Address: weishui industrial park pingyi , linyi, shandong, China, 273308
Tel: 8618753956296
pingyi Baier Building Materials Co., Ltd. Founded in 2002 ,Located in the foot of scenic mountain Meng, in the city of Pingyi, Shandong Province---the capital of Chinese gypsum board and plywood. Takes up an area of 150,000 square maters. So the company has the unique resource and position advantages, convenient traffic has its own import and export right, who are basically produce and sale the gypsum board , light steel drywall framework, PVC Laminated Gypsum ceiling tiles, plywood and so on. Welcome you to cooprate with us!
