C Purlin Roll Forming Machine

Description:
This C purlin forming machine is used to manufacture series of C-shaped steel purlin. The machine is mainly composed of uncoiler, flattening device, forming machine, cutting equipment, collection table, hydraulic station, and control system, etc. Controlled by PLC, this machine is easy to operate. This equipment utilizes combined mould design, and so a C purlin forming machine can manufacture products of many different specifications. In that way, it saves production cost as well as improves our product competitiveness.

Properties:
The frame of C purlin forming machine adopts formed steel construction and after welded, this machine utilizes integrity processing technology. It enjoys rational and beautiful structure, strong carrying ability, and stable and reliable performance. The forming roller of this machine is designed by professional technicists.

The machine undergoes high precision processing and heat treatment before chromeplate. So this machine is characterized by high forming precision and long service life. The main components of this device are from products of famous brands, thus ensuring the whole performance and quality. Controlled by PLC, this machine is easy to operate, thus workers without special training can operate it very well. This equipment is convenient to debug, and enjoys low noise and high efficiency.

Parameters:
1. Suitable material: cold rolling steel, hot rolled coils, galvanized coils and general carbon steel, etc.
2. Suitable thickness: 0.45-15mm, 1.5-3mm (depending on specific requirements of users)
3. Forming specifications: depending on specific requirements of customers
4. Forming speed: 10-15m/min
5. Main motor power: 5.5-18.5Kw (depending on specific requirements of users)
6. Hydraulic punching: hydraulic cutting without wastes
7. Hydraulic station power: 3-7.5Kw (depending on specific requirements of users)
8. Control system: PLC systems from Mitsubishi and Panasonic products
