Technical characteristics:
Reduce the drying process of complicated operation,and realize the automation;
With auto- cascade refrigeration technology and imported brand of French Taikang compressor to ensure the equipment running with low noise, large refrigerating capacity and water catcher capacity, that reduce the freeze drying time.
With imported brand dry filter,high efficiency filter refrigerants, that prevent the impurities and moisture into the refrigeration system;
Operating system with the manual and automatic operation of the two kinds of working mode, that greatly improving the selectivity of freeze dry operation;
LCD touch screen display, PID intelligent control, display the drying process with curve and data, and provide more information for the user of the drying process;
Shelf with silicone oil as medium, the temperature error 1 ℃ or less, the drying effect is uniform;
Shelf temperature adjustable, controllable,which can fumble for the production process;
Configuration of charging valve,can be filled with dry inert gas;
Cold trap and working face are stainless steel material, corrosion resistant, easy to clean;
Drying chamber adopts high density colorless transparent organic glass door, ensure safety, both the user and can be observed clearly in the process of operating the changing process of the material.
The drying chamber is made of high density of colorless transparent organic glass doors, both to ensure security, users can clearly observe the changes of materials during the operation process .

Commodity parameter：
Shelves temp（℃）：-50～+70
Cold trap temp（℃）：-80
Vacuum degree（Pa）：<10
Cold surface area for freeze drying（m2）：1
Water capture capacity（Kg/24h）：15
Tray specification（L*W*H mm）：360*480*15
Shelf layers (layers)：6
Load materials（L）：15
Material tray spacing(mm）：70
Material tray temperature difference（℃）：±1
Cooling：Air-cooled
Electric defrost：have
Gland way：not
bottle（ф22 mm、ф16 mm、ф12 mm）：2016、3960、7200
Voltage:380V/50Hz
