BATTERY POWERED PUNCHING TOOL
ED-12
The ED Series give another option for a fast and and reliable way to punching operation. The tool comes standard with two 18V,4.0Ah Li-ion batteries and one charger, motor drives, Micro-computer control system, OLED display and double valve hydraulic system.
| Rated pressure: | 120kN | ||
| Stroke: | 27mm | ||
| Max Round Punch size: | 61.5mm dia in 3.5mm mild steel | ||
| Time/work: | 6s(61.5mm dia in 3.5mm mild steel) | ||
| Punch/charge: | 180cycles/per charge | ||
| Voltage/capacity: | 18V/4.0Ah | ||
| Charging time: | 80 mins | ||
| Charging voltage: | AC 100V~240V ;50~60Hz | ||
| Package: | Plastic box | ||
| Size of tool: | 352x322x78mm | ||
| ACCESSORIES: | |||
| DESCRIPTION | HOLE SIZE (TYPE D) | ||
| Φ(INCH) | Φmm | ||
| 1/2" Conduit Size Punch&Die | 7/8" | 0.885 | 22.50 |
| 3/4" Conduit Size Punch&Die | 1.115 | 28.30 | |
| 1" Conduit Size Punch&Die | 1.362 | 34.60 | |
| 1-1/4" Conduit Size Punch&Die | 1.701 | 43.20 | |
| 1-1/2" Conduit Size Punch&Die | 1-15/16" | 1.951 | 49.60 |
| 2" Conduit Size Punch&Die | 2-3/8" | 2.146 | 61.50 |
| 7/16"×3/4" Draw Stud | 1pc | ||
| 3/4"×3/4" Draw Stud | 1pc | ||
| Spacer | 1pc | ||
| Battery: | 2 pcs | ||
| Charger: | 1pc | ||
| Sealing ring of cylinder: | 1set | ||
| Sealing ring of safety valve: | 1set | ||
