Automatic Welding Machine T beam / T-Bar Production Line For Shipyard

?

?

Description:

?

?

Reduce production period.

Reduce production costs.

Improve the quality of products.

Reduce labor intensity.

?

?

?

Applications:

?

?

Used for assembly line production of T beam in large and medium-sized shipyard, mainly consisting of feeding device (magnetic crane), chamfering machine, fixed-welding machine, feeding roller conveyer, T beam welding machine, discharging roller conveyer, straightening machine, polishing and painting devices, discharging devices (magnetic crane), etc.

?

?

?

Specifications:

?

?

- - - -
? | SPECIFICATION | REMARK |
T-BAR | L-BAR |
WEB | HEIGHT | 300~900 mm | 300~900 mm | Max. 1,978kg |
THICKNESS | 10 ~14 mm - | 10 ~14 mm - | ? |
FACE PLATE | WIDE | 100~300 mm 301 3 mm | 100~200 mm 301 3 mm | Max. 1,413kg |
THICKNESS | 18 ~30 mm - 30 mm | 18 ~30 mm - 30 mm | ? |
LEG LENGTH | 5.5~8 mm | 5.5~8 mm | ? |
BUILT-UP LENGTH | 5,000 - 22, 000 mm | 5,000 - 22, 000 mm | Max. 3,391kg |
- - - -

?

?
