Anti-explosion metallized film capacitor CBB65

Air conditioner capacitor , oil capacitor, motor capacitor, IGBT capacitor, CBB65 capacitor,motor run capacitor, aluminum case capacitor ,anti-explosion capacitor ,inverter welding capacitor, fan capacitor, CBB61 capacitor.

The capacitor takes heavy-edge metallized Al/Zn film as electrodes and dielectric. The elements are tight winded by high-velocity winders and canned in aluminum cases. Refined castor oil is adopted as impregnation agent treated in vacuum and high temperature condition. Those make a more reliable performance and longer lifespan for a capacitor. Meanwhile the second generation of mechanical anti-explosion design is selected as blast-proof secure measure for our capacitors. The reliability is more affirmatively enhanced.
Applications:
Broadly applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency for family air conditioners and high power illuminators for the sake of power factor compensation.
Technical Specifications:
Standard：IEC 60252-1:2001
Technical features：
Climate type：40/70/21 or 40/85/21
Capacitance tolerance：± 5%
I.R：≥3000S（MΩ·μF）
Dielectric dissipation factor：tgδ≤0.002 (50Hz～100Hz)
Application requirements：
Altitude：≤2000m
Residual voltage while loading: less than 10% of rated voltage.
Allowed maximum voltage: less than 1.1 times of rated voltage
Permissible maximum current: less than 1.3 times of rated current.


Rated voltage(VAC):200,250,370,400,440,
450,600,700,1200
Nominal capacitance(UF):3,4,5,7.5,10,12.5,15,17,20,22.5,
25,30,35,40,45,50,55,60,70,80,100,
25+5, 30+5, 35+5, 50+5, 60+5, 70+5, 80+5…

Note：1、Other capacitance and dimension serials can be specified in compliance with customer& acute;s request. 2、Terminal forms can be made in conformity to the requirements of agreements with customers.
