Aluminium plastic Alu-Alu blister packaging machine - ET-15
Aluminium plastic Alu-Alu blister packaging machine For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale Aluminium plastic Alu-Alu blister packaging machine, Made in China, High Quality Products!, China aluminum plastic blister packing machine, Aluminium aluminium blister packaging machine Supplier, Manufacturer.
Application:
Blister packing machine is suitable for the blister packaging of capsule, tablet, big honey pill, candy, liquid, paste, syringe as well as irregular shape tablets, the sealing could be Al-plastic, paper-plastic composite and Al-Al . Blister packaging is widely used in pharmacy, healthcare food, cosmetics, medical equipment industry etc, fully up to GMP standard.
Main parameters
Model: ET-160
Cutting frequency: (Al/plastic) 25-60(times/min) (Al/Al) 20-30(times/min)
Production Capacity: (Al/plastic)：6000-14000plates/hour, (Al/Al):4800-7200plates/hour
Max Forming Depth: (Al/plastic)：22mm, (Al/Al):18mm
Stroke range: 30-130 mm (could be customized)
Total Power: 220/380V, 50/60Hz (could be customized accordingly)
PVC hard sheet: 0.25-0.5×260 mm
Dialyzing paper: 50-100g×260 mm
PTP Aluminum Foil: 0.02-0.035 ×260 mm
Air source: 06-0.8Mpa
Air consumption: >=0.3m?
Cooling system: Condensate (self) or cold circulating water (optional)
Overall dimension: 5430×755×1680mm
Weight: 2000KG
Eta Packing Machine,Co.,Ltd.
Address: Hongqi Industrial Area ,Jinhu Street, Rui'an City,Zhejiang, Ruian, Zhejiang, China,
Tel: 0086-187-59295428
Eta Packing Machine,Co.,Ltd, founded in 2005, is one of China's leading automatic packaging equipment manufacturer. We have been in the line of food and medicine packaging industry for many year.
Our products are: cartoning machine, blister packing machine, liquid filling capping machine, automatic packaging design and packaging solutions.
Some of our products were rewarded the provincial New Hi-tech products and won a high reputation domestically and abroad.
Eta, for dedicated Packaging Solutions!
