Stationary type block separator
?
?
?
a) Uses
Separator?is?one?of?the?JQF-6?series?machine.?It?can?help?to?separate?block?without?manpower.?
?
b)??Main?Technical?parameter
?
# 1, Max?Dimension
# ???Length:7485mm????width:2913mm?????Height:3660mm
# 2, Weight:8500kg
# 3, Lifting?oil?cylinder???Dia=φ150mm??Stroke=1750mm
# 4, Locking?oil?cylinder??Dia=φ40mm??Stroke=50mm
# 5, Separating?oil?cylinder???Dia=φ125mm??Stroke=25mm
?
?
c)??Structure
?
The?separator?is?composed?of?frame,?separator?parts?and?hydraulic?lifting?system,?etc.
# Frame?and?separator?parts?are?joined?by?section?steel,?steel?plate.
# The?power?supplied?by?the?hydraulic?station.
?
?
d)??Work?Principles
?
When the finish product transported under the separator with side plate roller, the separator separates the block layer by layer from top to bottom. (the up separating parts clamp the up layer block and the down parts clamp the down layer of the block. After finish, the separating cylinder extends, separate the up and down separating parts, so that the block also separate, the rest can be done in the same manner)
?
?
?
e)??Quick-wear?parts
?
no ? ? ? ??specifications ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? nos.
1????????????oil?cylinder??????dia=150?Stroke=1750????????????????1?
2????????????rolling?bearing?????6314 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?2
3????????????bearing???????????22316 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?1
4????????????oil?cylinder??????dia=40?Stroke=50 ? ? ? ? ? ? ? ? ? ? ?1
5????????????bearing?????????308 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? 2
6????????????oil?cylinder??????dia=125?Stroke=25 ? ? ? ? ? ? ? ? ? ?6
?
?
?
?
?
?
?
