50KN Stroke 1000mm Grade 1 Package Testing Equipment with Tensile Compression Bending

?

?

50KN Stroke 1000mm Grade 1 Package Testing Equipment with Tensile Compression Bending

?

?

1. Specifications

??

1)?Digital display?
2)?High precision and easy to operate?
3)?Steady working?
4)?Reliable results

?

?

2. Use

?

It is suitable for doing testing experiments such as the tensile, compression, bending and shear testing for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.

?

?

3. Features

?

1)?high accuracy

2)?high performance

3)?superior software program

4)?muti-fuction,capable of performing tensile test,compression test,bending test,shearing test,tear test and peel strength test when used with relevant fixtures.

?

?

4. Technical parameter

?

- - - -
Capacity(optional) 250N, 500N, ?1KN, 2KN, 5KN, 10KN, 20KN, 50KN
Unit(switch) | N,kN,kgf,Lbf,MPa,Lbf/In2,kgf/mm2 |
Load Resolution | 1/25000 |
Load Accuracy | ±1% |
Load Magnifying Rate | Section-less |
Stroke(exclude the grips) | 1000mm |
Effective Width | 400, 500mm optional |
Test speed | 10~100mm/min |
Speed Accuracy | ±1% |
Stroke Resolution | 0.00125mm |
Software | Closed-loop control software |
Motor | AC motor |
Transmission Haulm | high accuracy of ball screw |
Main Unit Dimension(WxDxH) | 1080x540x1775mm |
Main Unit Weight | 450kg |
Power | AC220 10A or specified by user |
- - - -

?

?
