4A-2S Pipe Bending Machines

CJ-38CNC Mandrel Tube Bender

4A-2S Pipe Bending Machines
Get Quote

38CNC-4A-2S Automatic Pipe Bending Machine, equipped with a full-function device for bending three-dimensional space pipes, completes the entire pipe bending process automatically upon program input. The machine features easy operation, stable performance, high work efficiency, and a high safety factor, making it the ideal equipment for the pipe processing industry.
Features
4.Advanced Tube Bending Technology: Combines rich bending process experience with sophisticated mold design and manufacturing. Includes an automatic oiling system to enhance bending quality and extend mandrel life.

5.High-Performance Electrical Control System: Features robust and stable Japanese Mitsubishi servo components, including drives, motors, and a large-capacity CPU capable of managing up to 400 file edits.

3.Versatile and Safe Operation: Offers jog, single, and automatic operational modes with integrated circuit block structure for reliable hydraulics. Ensures safety with limit switches and an emergency stop button.

6.Flexible Bending Capabilities: Equipped with a mandrel mechanism for both mandrel and mandrel-less bending, adaptable to various profiles with interchangeable molds.

Parameter:

Type

 38CNC-4A-2S

Description

Parameter

Max Bending Diameter

38×2mm(3Dcarbon steel)

Max Feeding Length

2200mm(Custom)

Feeding Method

Direct/Clip

Max Bending Radius

200mm

Max Bending Angle

190°

The number of bends per pipe can be set

45pcs

Bending Speed

MAX80°/S

Rotating Speed

MAX200°/S

Feeding Speed

MAX1000mm/S

Bending Angle Precision

±0.15°

Rotating Angle Precision

±0.1°

Feeding Length Precision

±0.1mm

Rotary Servo Motor

0.75KW

Feeding Servo Motor

1KW

Bending Servo Motor

3KW

Machine Dimensions

5200*1350*1230mm
