4 layer TG circuit board, China 4 layer TG circuit board Supplier

4 layer TG circuit board - HS-021

4 layer TG circuit board For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale 4 layer TG circuit board, Made in China, High Quality Products!, China Four-layer PCB for Alarm Systems, 4-layer PCB with Immersion Gold Supplier, Manufacturer.

Layers: 4 layers
Board thickness: 0.8mm
CAD software: CAM350 and Genesis 2000
Finished copper thickness: 1oz
Aspect ratio: 8:1
Surface finish: immersion tin
General capability:
Material: FR4, Mid-TG150, and high T-G170 with KB class-A or SY laminate
Board thickness: 0.2mm to 3.2mm
Finished copper thickness: max 4oz
Min trace width/spacing: 0.1/0.1mm (4/4 mil)
Min hole: 0.2mm (8 mil)
Surface finishing:
HAL (lead-free)
Immersion Ni/Au (Au: maximum 0.125um, Ni: maximum 5um)
Entek coating (OSP)
Immersion Ag
Immersion Sn (Sn:maximum 1.2um)
Peelable mask: peters SD2955
Kapon tape
RoHS compliant

Get Quote

Haosens Technology Co.,Ltd

Address: 14,YuMin Road,ShaTou Industrial Park,ShaJing Town,Bao An District, Shenzhen City, Guangdong Province, P. R. China, Shenzhen , Guangdong, China, 518104
Tel: 86-755-29898591
Established in 1999, Haosens Technology Co.,Ltd is a professional Electronic Technology Group.We specialize in manufacturing Printed Circuit Board(PCB) and PCB Assembly(SMT and DIP).Abiding by the principle of "Quality Guarantee,Effective Management,Customer paramount",we are always attaching great importance to the quality control and hi-tech,which are highlighted throughout all the manufacturing and after-sale process.By passing the ISO9001,ISO14001,UL,and providing customer with good quality and high efficiency ODM and OEM service.
