The 250VO-25L series vacuum drying oven is CE certified dry oven. A 50-500ml flow meter is installed in the front panel for user to simply control and create a gas environment in the chamber. All necessary accessories can be supplied including vacuum pump, fittings, hoses, etc.

Features of Vacuum Drying Oven:
1) Radiant warm wall heating system provides optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.
2) 3& quot; (7.6 cm) glass wool insulation prevents heat loss from working chamber
3) Silicone door gasket and positive latch door maintain seal at all vacuum levels
4) Exclusive polycarbonate safety shield protects door glass
5) 28 segments programmable digital temperature controller with +/- 1.5C accuracy
6) Maximum Heating Rate: 4~6C/min
7) Vacuum fittings require .25& quot; (6.35 mm) I.D. tubing
8) Easy-to-clean #304 stainless steel chamber interior
9) 2 stainless steel shelves were included for immediate use
10) Vacuum and air lines constructed with corrosion-resistant stainless steel tubing for optimum chamber cleanliness and long term performance.
Vacuum Drying Oven Operation:
1) For using under vacuum, it is necessary to have the vacuum pump
2) 28 segments temperature profile programmable
3) Vacuum level displayed on gauges from 0 to 30& quot; Hg
4) PID precision Digital Power controller controls temperature with a uniformity of +/-5C@ 100C; 25& quot; Hg at center hot zone, 6& acute;x6& acute; center area only) and built-in over temperature protection.
