16ch Active CCTV Video Receiver With Terminal Block (VB1610JR) - No.1-1
16ch Active CCTV Video Receiver With Terminal Block (VB1610JR) For Sale, Most Competitive Price, Fast Delivery, Custom Service, Wholesale 16ch Active CCTV Video Receiver With Terminal Block (VB1610JR), Made in China, High Quality Products!, China 16ch Active CCTV Video Receiver With Terminal Block (VB1610JR), Active Video Balun, Supplier, Manufacturer.
16ch Active CCTV Video Balun Receiver with Terminal Block (VB1610JR)Description:The VB1610JR active video receiver receives balanced signal to converts it into unbalanced signal and raises the received signal with perfect receiving effect, which can be applied for the occasions such as video monitoring and video meeting and can transmit four channels of video image simultaneously via a 8-core Cat-5 twisted pair wire. It can simplify the wiring project and save wire use quantity.Features:1.?Adopt differential signal transmission with excellent anti-jamming ability2.?Save project wire expenses, each a pair of twisted pair wire transmits one channel of video signal and one common Cat-5 unshielded twisted pair wire can simultaneously transmit four channels of video signal3.?The farthest transmission distance will be 1500m if it is used with passive transceiver and the farthest transmission distance can reach 2400m if it is used with active transmitter 4.?Outstanding interference rejection, transient protectionTechnical specifications:16ch Active CCTV Video Balun Receiver with Terminal Block (VB1610JR)Video FormatNTSC,?PAL,?and?SECAM?Frequency ResponseDC?to?8MHzAttenuation0.5dB?typCMRR60?dB?ImpedanceCoax, Male BNC75?ohms?Terminal Block100?ohmsWorking environmentWorking?Temperature-10℃?to?+50℃?Storage?Temperature-30℃?to?+70℃Humidity?0?to?95%Wire TypeUTP5ConnectorFemale BNC, RJ45 and Terminal BlockPowerAC90-260VCaseAluminum alloy caseDimension430mm*182mm*44mmType of the required wire:Unshielded Cat-5 or above twisted pair wire (Please use standard Cat-5 or above twisted pair wire. The wire quality will directly affect the transmitted image effect and transmission distance.)Characteristic impedance: 100Ω±20ΩDC loop resistance: 18Ω/100mDifferential capacitance: 62pf/m (Maximum)Connection method：Clamp the modular plug for a Cat-5 unshielded twisted pair wire according to the connection order of TIA/EIA-568B (please refer to the following figure) and connect the clamped modula
